Specification
| Engine | UNIT | WE215F | WE375F | WE560F | WE750F |
|---|---|---|---|---|---|
| Engine Mode | WEICHAI WP6G | WEICHAI WP10.5H | WEICHAI WP14T | WEICHAI WP15H | |
| Number of Cylinders | 6 | 6 | 6 | 6 | |
| Max.Torque/Speed | n-M/RPM | 710/1600 | 1470/1300-1500 | 2900/1200-1500 | 2900/1200-1600 |
| Displacement | L | 6.75 | 10.5 | 13.5 | 15.33 |
| Main Performance | |||||
| Operating Weight | kg | 21800.00 | 37000 | 53400 | 71580 |
| Rated Power | kW | 129.00 | 247 | 562 | 566 |
| Bucket Capacity | m3 | 1.1 | 1.9 | 3.6 | 4.5 – 5.0 |
| Bucket Digging Force | kN | 133 | 221 | 314 | 404 |
| Arm Digging Force | kN | 106 | 192 | 250 | 348 |
| Max.Traction Force | kN | 232 | 248 | 288.4 | 416.2 |
| Max.Walking Speed | km/h | 5.8 | 5.6 | 5.4 | 4.3 |
| Min.Walking Speed | km/h | 3.6 | 3.4 | 3.2 | 2.8 |
| Rotary Speed | r/min | 11 | 9.5 | 6.9 | 6.3 |
| Gradeability 35, % | % | 35 | 35 | 70 | 70 |
| Ground Pressure | kPa | 37 | 73 | 90.8 | 86.4 |
| Hydraulic system | |||||
| Max.Main Pump Flow | L/min | 125×2 | 685 | 766.1 | 855 |
| Main Safety Valve Pressure | MPa | 34.30 | 34.3 | 34.3 | 35 |
| Oil Capacity | |||||
| Fuel Tank | L | 420 | 630 | 780 | 940 |
| Hydraulic Tank | L | 206 | 316 | 450 | 640 |
| Engine Oil | L | 19.5 | 52 | 38 | 60 |
| Dimensions | |||||
| Shipping Length | mm | 9680.00 | 11350 | 12240 | 12560 |
| Shipping Ground Length | mm | / | 6760 | 7375 | 7900 |
| Boom Height | mm | 3322.00 | 3615 | 3915 | 4240 |
| Shipping Width | mm | 3000.00 | 3200 | 3340 | 4250 |
| Cab Height | mm | 3046.00 | 3246 | 3396 | 3560 |
| Ground Clearance of Counter Weight | mm | 1085.00 | 1224 | 1410 | 1574 |
| Min.Ground Clearance | mm | 467.00 | 516 | 568 | 871 |
| Tail Turning Radius | mm | 2980.00 | 3610 | 4040 | 4330 |
| Length to Center of Rollers | mm | 3360.00 | 4140 | 4430 | 4570 |
| Track Length | mm | 4155.00 | 5070 | 5500 | 5810 |
| Track Gauge | mm | 2200.00 | 2590 | 2740 | 2810/3350 |
| Track Shoe Width | mm | 800.00 | 600 Double-Rib | 800 | 600-800 |
| Hood Height | mm | / | 2892 | 2795 | |
| Rotary Platform Width | mm | 2740.00 | 3025 | 3190 | 4250 |
| Working Range | |||||
| Max.Digging Height | mm | 9915 | 10025 | 10675 | 11345 |
| Max.Dumping Height | mm | 7140 | 7070 | 7345 | 7475 |
| Max.Digging Depth | mm | 6630 | 6960 | 7175 | 6800 |
| Max.Vertical Digging Depth | mm | 6175 | 4707 | 6663 | 4358 |
| Max.Digging Radius | mm | 9845 | 10770 | 11545 | 11550 |
| Max.Ground Digging Radius | mm | 9660 | 10556 | 11317 | 11260 |
| Min.Turning Radius | mm | 3255 | 4427 | 4939 | 4754 |
| Other Specifications | |||||
| Boom Length | mm | 5700.00 | 6500 | 6900 | 6800 |
| Arm Length | mm | 2925.00 | 2800 | 2900 | 2800 |
| Track Section Number(each side) | 45 | 49 | |||
| Track Roller Number | 7 | 9 | 9 | 9 |
