Specification
| Drive Line | 6×4 | |||||||||||
| Weight | GVW(Kg) | 25000 | ||||||||||
| Kerb Weight (Kg) | 8800 | |||||||||||
| Dimensions | Overall Dimension | 8800×2550×3150 | ||||||||||
| Wheel Base | 4200+1350 | |||||||||||
| Front/Rear wheel track (mm) | 2040/1850 | |||||||||||
| Front/Rear overhang(mm) | 1550/1700 | |||||||||||
| Approach/Departure angle (°) | 27/17 | |||||||||||
| Performance | Max.speed (km/h) | 77 | ||||||||||
| Max.gradeability(%) | 30 | |||||||||||
| Minimum turning diameter (m) | 18.5 | |||||||||||
| Engine | Model | WP10.380E53 | ||||||||||
| Horsepower (Hp) | 380 | |||||||||||
| Maximum output Kw/r/min | 280/1900 | |||||||||||
| Maximum torque N.m/r/min | 1630/1200-1500 | |||||||||||
| Type | 4 stroke high pressure common rail diesel engine,6 cylinder in-line with water cooling,supercharging intermediate cooler | |||||||||||
| Borex Stroke | 126x130mm | |||||||||||
| Valve | 4 | |||||||||||
| Displacement(L) | 9.726 | |||||||||||
| Transmission | Model:HW19709XST,MT Type:9 forward and 1 reverse |
|||||||||||
| Cabin | Model:H77L-R Low Roof Type:4 point Air suspension Cabin,Spring cushioned driver seat,Automated Air-conditioning,Daytime Running Light,Electrical Cabin Lifting,Dual-tone air horn,MP3,Power Window |
|||||||||||
| Clutch | Model:CH430-21,Type:Diameter 430mm diaphragm spring clutch | |||||||||||
| Steering | Model:ZF8098,Type:Steering hydraulic steering with power assistance | |||||||||||
| Front Axle | Model:VGD95,Type:Forging I-beam front axles equipped with drum brake,Loading capacity=9500Kg | |||||||||||
| Rear Axles | Model:MCP16ZG Type:central+hub reduction,drum brake Loading capacity:2×16000 ratio·477 |
|||||||||||
| Suspension | Front | 9 pcs Semi-elliptical leaf springs with shock absorbers and stablilizer | ||||||||||
| Rear | 12 pcs Bogie leaf springss with divided balance shaft and stabilizer | |||||||||||
| Brake System | Service brake | Dual circuit compressed air brake | ||||||||||
| Parking brake | Spring storage energy without air | |||||||||||
| Auxilliary brake | Engine exhaust brake | |||||||||||
| Rim/s Tyres | 22.5×9.00 /295/80R22.5 | |||||||||||
| Electrics | Voltage:24V; Batteries:2x12V,180AH |
|||||||||||
| Fuel Tank | Aluminium fuel tank with locking fuel cap Capacity:300L |
|||||||||||
